* Waveform reference for visual comparisons and automatic pass/fail testing of waveforms * Up to 1000 V independently floating isolated inputs * TrendPlot™ paperless chart recorder for trend analysis up to 22 days * 27,500 points per input record length using ScopeRecord™ mode

Fluke 192b scopemeter manual manuals#

* Automatic capture and replay of 100 screens Manuals Product Registration Data Sheet Virtual Product Demo Brochure Portable Oscilloscopes > Fluke ScopeMeter® 190 Series Specifications Bandwidth Fluke 199B, Fluke 199C:200 MHz Fluke 196B, Fluke 196C:100 MHz Fluke 192B: 60 MHz Real-time sample rate Fluke 199B, Fluke 199C:2.

Fluke 192b scopemeter manual update#

* Fast display update rate for seeing dynamic behavior instantaneously * Digital Persistence for analyzing complex dynamic waveforms like on an analog scope * Frequency Spectrum Analysis using FFT (190C) (NEW) * Connect-and-View™ automatic triggering and a full range of manual trigger modes * High waveform resolution of 3,000 datapoints per channel (NEW) * Choice between a high resolution Color display (190C Series) or Black & White display (190B Series) * Up to 2.5 GS/s real-time sampling per input * Dual-input – 200, 100 or 60 MHz bandwidth They’re rugged, compact and battery powered.

They offer up to 200 MHz bandwidth for capturing high frequency signals, as found in today’s state-of-the-art electronics, 2.5 GS/s real-time sampling and advanced memory and triggering functions. ScopeMeter 190C and 190B Series have specifications you typically only find on high-end bench oscilloscopes. Connect-and-View automatic triggering and a full range of manual trigger. With up to 200 MHz bandwidth, 2.5 GS/s real-time sampling and a deep memory of 27,500 points per input they’re ideal for engineers who need the full capabilities of a high-performance oscilloscope in a handheld, battery powered instrument.

For the more demanding applications, the ScopeMeter 190 Series high-performance oscilloscopes offer specifications usually found on top-end bench instruments.
